The Walksnail Avatar HD Lite Camera / Mini 1S VTX Kit features a Lite digital camera, antenna, and mini VTX (with heat sink) that works with HD Goggles such as the Walksnail Avatar and Fat Shark HD Dominator. This lite mini HD VTX combo has lower latency than the competitor at an average of 22ms, with an onboard DVR, 5.8GHz frequency, 8Gb internal storage, and a switchable aspect ratio.
Note: This kit includes the updated HD Lite camera, not the Nano camera.
Features
- Lower latency than the competitor at an average of 22ms
- Walksnail Avatar Mini 1S VTX Module (with Heatsink)
- Lightweight Mini VTX great for the 75x Quad
- Walksnail Avatar HD Lite Camera
- Walksnail IPEX 1S Lite Antenna
- Built-in 8Gb Internal Storage
- 1080p Screen Resolution
- Switchable Aspect Ratio
- 5.8GHz Frequency
- Heatsink Design
- Onboard DVR
- Canvas Mode
- 170° FOV
- 3.1V-5V
Specifications
AVATAR HD LITE CAMERA
- Resolution: 1080P/60fps,720P/120fps,720P/60fps
- Shutter Rolling: Rolling shutter
- Dimensions: 14x14x16mm
- Min.Illumination: 0.001Lux
- Model: Avatar Lite camera
- Image Sensor: 1/2.7”1nch
- Ratio: 16/9 4/3
- Aperture: F2.0
- Lens: 2.1mm
- Weight: 1.8g
- FOV: 170°
AVATAR MINI 1S VTX MODULE (WITH HEATSINK)
- Transmitter Power: FCC<25.5dBm / CE <14dBm / SRRC <20dBm / MIC <25dB
- I/O Interface: JST1.0 x 6 (Power In) to JST0.8 x 4 (USB)
- Operational Frequency: 5.725-5.850GHz
- Operating Temperature: -20° to 40°c
- Supported FC Firmware: Betaflight
- Video Resolution: 1080p / 720p
- Dimensions: 30x30x6.5mm
- Antenna Connector: IPEX
- Bitrate: 25mbps/50mbps
- Mounting: 25.5x25.5mm
- Latency: 22ms Average
- Internal Storage: 8GB
- Input Voltage: 3.1-5V
- OSD: Canvas Mode
- Weight: 5.1g
- Channels: 8
AVATAR 1S LITE VTX ANTENNA
- Bandwidth: 5.6-5.9GHz (5600-5900MHz)
- Input Impedance: 50Ω
- Gain: 1.6dBi Average
- Polarization: Linear
- Connector: IPEX-1
- Length: 70mm
- VSWR: ≤1.5
- Weight: 0.5g
- Width: 5mm
Includes
- 1x Walksnail Avatar HD Lite Camera w/ Avatar Mini 1S VTX (With Heatsink)
- 1x Walksnail Avatar IPEX-1 1s Lite Antenna
- 1x 4-Pin Power Cable
- 2x 1.4x10mm Screws
- 4x 1.4x8mm Screws
- 1x 4-Pin USB Cable
WALKSNAIL Avatar HD mini 1S Lite Kit
$84.99 Regular Price
$80.75Sale Price
